A critical look at crampon fit and design


















There are many different crampon manufactures. I am not so much interested in manufacturer or style of crampon as I am in the actual boot to crampon interface, in other words the "fit" of the crampon.

If you have ever lost a crampon on technical ground you know the surprise and general helplessness that goes right along with it. That is if you live through the experience.

I've only done it once. For the sake of documentation I was attempting to show a novice climber what not to do and some how literally kicked my right crampon off. As I watched it tumble down the waterfall I too started to topple over and slide.

The only thing that caught me was the dumb luck of catching my tool's pick on his buried pick as I went buy. Thankfully his placement held and I didn't knock him off as well. Other wise? It would have been a 500'+ foot tumble and most likely death, certainly serious injury.

Humbling and just as sobering. I had soloed some difficult terrain in those same boots and crampons. To this day I am not sure if my set up was bad or just my adjustments on the straps.
I was damn lucky and it cooled my jets for soloing (or just climbing) ice for awhile.

Either way it is not something I ever want to repeat.

Not everyone will recognize the crampons in the picture. But in 1980 they were one of the models that were putting up the first of the WI6 routes. They were a rigid model by SMC. Chouinard's rigid design while revolutionary always had a durability/reliability issue. The earliest clip on Salewa/Chouinards were the crampon of choice for many of us who disdained the weight of Lowe's Footfang. Foot Fangs were a quick glimpse into the future of crampon and not all of it was good news imo.

Back then we used Beck neoprene coated nylon straps (also sold by Chouinard) to hold the crampons on. Clip on crampon bindings were still new to climbing. While that turned out to be a great idea 10 years years later. (mid 1980s) I had seen two different brands of a single crampon with the early clip on binding still attached before we hit the first ice field on the Eiger in '78. Crampons sitting in the rumble mid way up a big north face gives one a moment to pause and consider the consequences of that gear choice.

Part of the fit process on the older crampons (not Foot Fangs however) was to adjust the crampon to the sole pattern of the boot. And most importantly it seemed to me was to make the fit tight enough that you were unlikely to loose a crampon is you broke a strap or a crampon post.

The more rigid the crampon and boot interface the better the combination will climb. Actually let me go farther in that comment, the more rigid the boot sole and the more rigid the crampon the better the combination will climb on pure ice given a solid interface between the boot and crampon.

Looking at currently available equipment with 7 pairs of La Sportive boots (Spantik, Baruntse, Batura, Nepal Evo, Trango Extreme Evo, Trango Ice Evo and the Nepal Evo GTX all size 45) and 4 different brands of crampons ( Camp, Black Diamond, Petzl and Grivel and 7 models) ) it is interesting the observations you can make on crampon fit and how the difference in boot construction even between models in the same brand affect that fit.




























With the popularity of mixed climbing I am actually shocked at the sloppy interface between boot and crampons across the board. I don't claim to be a "M" climber but I understand how to hook a tool on rock and what it takes to climb at Hafner or on hard alpine mixed.

If you weigh in at 125 and have a size 7 foot not a lot is going to ruffle your gear if it is fit right. Hit 200# and have a size 12 foot and you can easily do things to a crampon that a 125# M12 climber has yet to dream of. An example is a front bail that turns into a shock absorber and can literally bounce off the lip of a boot. That might get anyone a little cranky. Add to a bad design, as a way to fix, the other bad design...with bail "laces" and you go from bad to worse.

I replace the Grivel "round" bails with something else and simply cut the additional retaining straps off the front bail of the BDs.

On the mixed terrain pictured below I noticed more than once I was climbing on the "ring" of a Grivel front bail. Not a comforting feeling. Just as bad I think is the large diameter wire and over size bails that BD uses. Bails hitting rock before your crampons do is a bad thing. Yes most every boot will fit BD crampons but precise they aren't. Of the three big manufactures only Petzl seems to have the front bails fit squared away. But then Petzl has the only front bails I know of that break. So may be "squared away" is a not really the right word. Crampons need to stay on the boot. Black Diamond has never had a breakage problem. I'll take reliability first, thank you! Everything is a trade off. And that is just a quick look at the front bails!

DT photo credit to DanielH and DaveB.

To be fair the crampon manufactures are hamstrung when it comes to boot fit. What is really needed is a DIN norm for rigid soled climbing boots. Then every crampon manufacturer would know exactly what they have to design to/with. After all the hard-goods guys are only half the real product on ice/mixed. You have to clamp a crampon to a boot sole to make a usable tool. I have 7 pairs of boots, all the same size and from the same manufacture. None of them fit the crampons I own exactly the same. Imagine the nightmare the crampons manufacturers go through every season as the boot technology and sole profiles change. Is it no wonder they build on the conservative side?

I'll repeat myself. We need a rigid sole mountain boot DIN norm.



I'll let you decide what is a good front bail/crampon fit for your style of climbing and what is not. My answer was to add Petzl bails to my BD crampons for a better fit and trust in the Petzl spiel that their bails are now reliable. It is a trim set up that fits all my boots well and drops a few oz. in the process.




There is nothing easy. cheap or guaranteed in all of this. I understand that. But I also get to point out the bad designs and ask that it be done better. More of us should! Speak up!







These are just shots of the front bails. While some front bails might not be the best set up, we should also be looking at the bottom of the crampons. To be specific just what the crampon covers on the bottom of the boot.




Most of us don't want to be climbing in "fruit boots" with no heel piece and only front pointing. It is a good direction for design to get lighter gear as long as we don't forget its real use. As important as the attachment system is and how much clearance the bails have from the boot, the real reason we use crampons is to "stick" us to ice and snow. How many points you have going down is even more important as those going forward if you want to climb with the least amount of effort on difficult terrain.




To my way of thinking the more down points the better. I'd rather have the weight and additional of traction that is the end result of skipping down points in a design. To lose weight, crampons have also lost "sole". By that I mean the crampons have lost surface area on the front half of the crampon generally. Less and less of your boot is being covered by the crampon. A quick look at the old Chouinard/Salewa rigid shows a crampon that almost perfectly covers the entire sole outline of the boot. Makes climbing on the crampon precisely, a lot easier.

More importantly we use a alpine/ice climbing crampon to "cut" steps when you want to rest from a front pointing position or help clear out a chopped ledge by kicking. How the down points are positioned and how many of them are on the crampon define how you can use your crampons to accomplish "cutting". Down points facing backward tend to skate your foot off when driving the foot forward with power to "cut" and don't allow you to kick efficiently to clear a step or a ledge.

The next selection of pictures is a grab bag of old and new crampons. Double click the photos and take a look at the difference in boot sole surface area coverage, the number and location of the down spikes and their obvious resulting traction or lack of traction.
























































The difference between lever lock heel bails is small but not without need for comment. Black Diamond and Grivel use a fairly large plastic lever. Both are comfortable on the back of a soft boot like the Trango Series from Sportiva. The Petzl lever? No so much. Painful in fact. Bad enough that I don't use the Petzl lever on anything but the heaviest boots. Nepal Evos and my dbl boots don't have an issue with the Petzl levers but I can't wear them on any of my Trango Series boots. It is just too painful.



Grivel and Black Diamond also use their retaining straps to give an extra safety feature by locking the levers in place with the added leverage and a tight strap. Not Petzl however. Hard to image a worse design for a crampon lever lock than what Petzl uses. Not only is the lever hard to get off when required but the retaining strap will only "retain" the crampon if you are extremely lucky and you pop a lever while climbing. The strap will not retain the lever against you boot. Take a look at the last picture in the next series. The lever down is with a TIGHT safety/retaining strap in place. Both Grivel's and Black Diamond's will retain the lever in the correct up position. It is a simple leverage issue. Petzl missed that. Black Diamond and Grivel did not. Weak......on Petzl's part. However you can fix the Petzl rear bail to be more reliable. You'll have to cut the adjustment ball on the top of the lever and then thread the safety strap through the top of the flip lever. Solves the problem but why are we required to fix it?

Easier and thankfully both Black Diamond and Grivel heel levers and locks will fit easily on the Petzl crampons. You can order up a pair from BD's customer service for a small fee and they snap right on.














With miles of ice climbing it is easy to look both backwards and forwards. The majority of pure ice lines were climbed with basic boots, ice tools and crampons. Some times I laugh at what we are using now and not in a good way. Most pure ice lines could be climbed with a club with a nail through it and hob nails.

What we have now for ice tools, boots and crampons makes ice climbing trivial in comparison to 30 years ago technology. The newest ice climbing gear is stellar in comparison so while I may sound like I am simply bitching, I am not. Ice tools are amazing these days. I am the perfect example of just how good they are. No question I am climbing harder ice now than I ever have because of the current hand tools. But boots and crampons have fallen behind the advances in ice tools. And in many ways boots and crampons have fallen behind some of the 30 year old technology! My 30 year old plastic boots and chromoly crampons will climb pure ice as good or better than anything available currently and they weight LESS!

Lucky for the manufactures that almost any crampon will work, as will almost any boot.

Call it a wake up call to the industry. And a invitation for you to join me in asking for better products. If nothing else take a critical look at your own gear and sort it out as required.

I'd like to see lighter weight boots and lighter weight crampons. Both with better over all traction all the while keeping the ability to front point with less effort. I'm not asking for much :)

To do that it is going to take a rethinking of basic designs and may be a critical look back to look forward.

3 comments:

Dane said...

This came in today from someone commenting. Not my personal experince or others that I know on the hinged Petzl products but worth passing along.

"I use petzl M10's and have La Sportiva Trango Evo L Gtx/Duratherm boots and have not had a problem with the Petzl lever"

Anonymous said...

Any experience fitting crampons to Nuptse's? My Grivel Airtech G12's fit my size 47 Nepal extremes very snugly (just long enough) but they don't go any where near the Nuptse (despite being half a size smaller 46.5) and also are very wide boots compared to the crampon width (nearly an inch overhang at widest point similar to the Grivel fourth from the left in your upside down pic. Notice Steve House using Newmatic binding g12's on Nuptse's in his Nanga Parbat photos, but he is sponsored by Grivel. Would another brand/model fit better for Alpine? Cheers
Mike

Dane said...

Mike,
One of the things that always bothered me about the Grivels on my dbl boots was how narrow the 'pons were across the sole. Seems you noticed this as well. I ended up just using the Grivels on smaller, much more narrow, single boots, Nepals and Trango Extremes.

I have the extra large bars for the G12s that are required for my size 45s with any of the dbl boots I own. Only used them once on my Spantiks and was never comfortable with them French technique on a steep side hill.

BD 'pons (Sabertooth or Cyborg) with clip heels and toes seem to fit most boots better than my G12s. I have been unable to get a good fit on any of the bigger boots with the Grivels. The best fit I did get used a Petzl front bale on the Grivels. I was never comfortable with them. They work fine on the much smaller La Sportive single boot models. All that said I do like how well the Grivels climb steep water ice and mixed.

I am not a big fan of the Newmatics by any manufacture. But guys like Steve House, Vince Anderson and Bill Belcourt (who also wears a size 45) have no problem using them (Grivel or Black Diamond) on hard technical ground. So they can't be that bad is my guess.

Maybe some one else can add more.
